RTS-006 amplifier-30 years focus on CATV, MATV & SAT TV. Network Communication OEM/ODM manufacturer

RTS-006 amplifier

（4017H）

Consultation hotline：0755-27091915

Place of Origin:Guangdong,China
Model Number:RTS-006 （4017H)
ITEM	4017D
Housing	Tin-PlatedZinc Die-Cast
Freq.	950-2300MHz
Gain	-9dB Max.
950MHz	17dB(Typ.), 15dB(Min.)
2300MHz	21dB(Typ.), 18dB(Min.)
Noise Figure	5dB Typ.
In/Out Return Loss
Input capablilty	85dBµV(3rd order Distortion)
(1dB Compression)	f1:988MHz f2:990MHz
Line Voltage	13V~18.5VDC
