3822

RTS-005

Consultation hotline：0755-27091915

Online Service

Parameter

Place of Origin:Guangdong,China
Model Number:RTS-005（3822）
ITEM
TYPICAL
QC LIMIT
TEST CONDITIONS
Freq. Range
Pass band
5-698MHz
Stop band
740-1000MHz
Insertion loss
Pass band
-0.5dB
-1.0dB Max
5-600MHz
-2.5dB
-3.5dB Max
601-698MHz
Rejection
Stop band
-55dB
-50dB
740-1000MHz
Reutrn Loss
-16dB
-12dB Min.
5-698MHz
Impedance
75 ohm
Connector
F Female
Dimensions
L88*D28.5*H6 mm
Weight
60g
