Parameter
| Place of Origin: Guangdong,China | ||
| Model Number:GDSW-002(FESW-17GP） | ||
| Support standards |
IEEE 802.310base-t IEEE 802.3u100base-tx IEEE 802.3 ab1000 Base-T IEEE 802.3x flow control IEEE 802.3 ad link aggregation IEEE 802.1d filtering tree (STP compatible) IEEE 802.1Q VLAN tagging IEEE 802.1x port based network access control IEEE 802.1p class of service, priority protocol IEEE 802.1s multiple filtering tree IEEE 802.1w rapid spanning tree |
|
| Interface |
10/100/1000BASE-T(RJ-45)×16 ports Wan/console port×1 Port Auto negotiation Auto MDI/mdi-x Full duplex/half duplex fixed(10/100Mbps configuration) |
|
| Switch performance |
Switching systems: Store & forward Switching fabric: 34 Gbps Packet buffer: 512 kByte Flash memory: 32mbyte Main memory: 128mbyte MAC address registration VLAN registration number (VID = 1-494): 256 Reset button: 1 second = restart body |
|
| Status LED |
Power LED × 1 Link / act × 17 Speed (green / orange) × 17 |
|
| Cooling fan | No | |
| Electrical specification | Rated input voltage | AC 100-240 V |
| Input voltage range | Ac90-264 V | |
| Rated frequency | 50/60 Hz | |
| Maximum power consumption | 11.2 w (0.21a a) | |
| Environment specification | Operating temperature | 0～50℃ |
| Humidity during operation | <80% | |
| Storage temperature | -20～60℃ | |
| Humidity during storage | <95% | |
| External dimensions |
W 235 × D 150 × H 38 (mm) (there is no projection.) |
|
| Weight | 1.2 kg (body only) | |
| Conformity standards | EMI standards | VCCI ClassB |
| Environmental standard | EU RoHS | |
| Accessories | AC power cable (L type 2p1e) | |
| Instruction manual (CD-ROM) | ||
| Instruction manual | ||
| Cable stop hook | ||
| L-type bracket | ||
| T-type bracket | ||
| Switching function | Port 802 | |
| Port mirroring | ||
| Flow control / receive only support | ||
| Broadcast storm protection | ||
| Spanning tree | ||
| Rapid spanning tree | ||
| Multiple spanning tree (IEEE 802.1s) | ||
| IGMP V2 / V3 snooing | ||
| MLD V1 / V2 snooping | ||
| DHCP snooping | ||
| BPDU transmission | ||
| EAP transmission | ||
| UDLD | ||
| Jumbo frame support | ||
| Ingress filtering | ||
| Hol blocking prevention | ||
| Port management |
Loop protection (LDF detection) Loop protection (detection of reception rate) |
|
| VLAN |
Port based VLAN Tag VLAN (IEEE 802.1Q) Multiple VLAN Dynamic VLAN |
|
| QoS function |
Number of queues Priority control (CoS / TOS / DSCP / policy base) Bandwidth limit Scheduling (absolute priority, WRR) |
|
| Authentication function / security |
IEEE 802.1x authentication (single host / multiple host / multiple authentication) 802.1x encryption (MD5 / TLS / TTLS / PEAP) Mac authentication Web authentication Port security Access reference Radius authentication |
|
| Management |
Cli Web browser settings Telnet SNMPv1 / V2C Log SNTP client DHCP client SNMP MIB MIB I (RFC 1213) Script Display statistics Download firmware and configuration files |
|
