GDSW-001 network switch

14Port-1

Consultation hotline：0755-27091915

Online Service

Parameter

Place of Origin: Guangdong,China
MODEL NO. : GDSW-001(14Port-1)
Name
Gigabit Switching HUB
Overview
1000M/100M/10M Swithing HUB 14 Port Metal housing,bulit-in power suplly,power control function
Support standards
IEEE 802.3ab (1000BASE-T)
IEEE 802.3u (100BASE-TX)
IEEE 802.3 (10BASE-T)
IEEE 802.3x (Flow Control)
Acquired Standard
VCCI ClassB
Interface
Standard
1000BASE-T/100BASE-TX/10BASE-T
port
RJ45 x 14 Port
Performance
Access method
CSMA/CD
Switching mode
Stock&forward
Switching fabric
28Gbps
jumbo farame
16Kbytes
Packet buffer
384Kbytes
MAC ADDRESS WNTRY
8000( max)
Transmission function
BPDU、EAPOL
Multicast
IGMP v1/v2/v3/MLD v1/v2
Status LED
Power (green) × 1, link / Act (green) × 14, speed (green / orange) × 14
Multicast (red)
Cooling fan
with out
Power Supply
Rated input voltage
AC100V(50/60Hz)
Grid input current
240mA
Maximum power consumption
6.3W
Environmental conditions
Action time
Temperature 0 to 50 degrees Celsius, humidity 90% or less
When keeping
Temperature - 20 - 70 degrees Celsius, humidity 95% or less
appearance
Inch method
W290 × D75 × H32 (mm)
Quality
721g (including mounting fittings)
Accessories
Power cord and instruction manual
