Parameter
|
Place of Origin:Guangdong,China
|
|||
|
Model Number:GDINS-006(Inserter-4A)
|
|||
|
Band width
|
|||
|
RF to RF+DC port
|
900-2150MHz
|
||
|
Insertion loss
|
|||
|
RF to RF+DC port
|
1.0dB
|
1.5dB max
|
900-2150MHz
|
|
Flatness
|
|||
|
RF to RF+DC port
|
±0.5dB max
|
In any 36MHz freq. band
|
|
|
Isolation
|
|||
|
RF to DC port
|
35dB
|
30dB min
|
900-2150MHz
|
|
VSWR
|
|||
|
RF &RF+DC port
|
1.4:1
|
1.5:1 max
|
900-2150MHz
|
|
DC Through voltage
|
|||
|
DC to RF+DC port
|
48V max
|
||
|
Continuous current
|
|||
|
DC to RF+DC port
|
4.0A max
|
When 24V dc is present at
|
|
|
These ports
|
|||
|
2.0A max
|
When 48V dc is present at
|
||
|
These ports
|
|||
|
Surge Withstand
|
1KV 10/700uS
|
All ports
|
|
|
Capability
|
IEC ECN61000-4-5
|
||
|
Connector
|
F Type female
|
All ports
|
|
|
Input power
|
+5dBm max
|
||
