GDSS-004 select switch

3731

Consultation hotline：0755-27091915

Place of Origin:Guangdong,China
Model Number:GDSS-004(3731)
1.Component Video
In/Out Impedance	75 ohms
Frequency Response	30 MHz
Insertion Loss	±0.1 Vpp
2.Composite Video
In/Out Impedance	75 ohms
Frequency Response	10 MHZ
Insertion Loss	±0.1Vpp
3.S-Video Video
In/Out Impedance	75 ohms
Frequency Response	10 MHz
Insertion Loss	±0.1Vpp
4.Stereo L/R Audio
In/Out Impedance	10k ohms
Frequency Response	100 KHz
Insertion Loss	±0.1Vpp
5.Toslink Digital Audio
In/Out Impedance	As per SPDIF
Frequency Response	10 MHz
Insertion Loss	±0.1Vpp
6.Power Required	10 VAC @ 300mA
7.Dimensions	310x45x195 mm
