RTS-041

(RG45 CABLE-2 )

咨询热线：0755-27091915

Place of Origin:Guangdong,China
Model Number:RTS-041(RG45 CABLE-2 )
ITEM	Description
Length	1500±30mm
RJ45 PLUG	8P8C
CONTACT	COPPER ALLOY,PLATED G/F
INSULATION	PC, CLEAR, UL 94V-0
UL 2835 CAT 5e,UTP, 26AWG 4PAIR
CONDUCTORS	26AWG(7/0.16BC)
INSULATION	HDPE,ID:095±0.05mm
JACKET	COOL GRAY 5U PVC OD:5.5±0.2mm
ELECTRICAL TEST
INSULATION RESISTANCE	10 MEGOHMS MIN. AT DC 300V
CONDUCTIVE RESISTANCE	2 OHMS MAX.
