RTS-026

( AC CABLE-1 )

咨询热线：0755-27091915

Place of Origin:Guangdong,China
Model Number:RTS-026(AC CABLE-1 )
ITEM	Description
Attachment plug cap	SP-05
Cord connector body	QP-007
Flexible cord	VCTF 3G 0.75㎜²
CONDUCTOR(material:BC)
Construction	30/∮0.178 ±0.008
Size	3G 0.75㎜²
INSULATION (material:PVC)
Average Thickness	0.54mm
Minimum Thickness	0.48mm
Diameter	2.35±0.10mm
JACKET (material:PVC)
Average Thickness	0.9mm
Minimum Thickness	0.7mm
Overall Diameter	7.0±0.2mm
APPROVAL MARK	Taiwan (BSMI)
Length	1830±50mm
