Place of Origin: Guangdong,China
|
|
MODEL NO. : GDSW-004 (10Port+2Port SFP）
|
|
Support specifications
|
|
|
4 x 10/100/1000Mbps RJ45 Port
8 x 10/100/1000Mbps RJ45 Port Support IEEE802.3at POE, Output power 65W (Max)
Support Auto MDI/MDIX & Auto Negotiation
|
|
|
IEEE 802.3 10Base-T,
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T,
IEEE 802.3x Flow Control Support (CSMA / CD)
|
|
|
Panel LED Power (Green) 、PoE max (Red)
RJ45 LED Link/Activity (Green) 、
Speed (1000M：Green 、100M：Orange、10M：None)
|
|
|
RJ45 10BASE-T：Cat. 3、4、5 UTP/STP
RJ45 100BASE-TX / 100BASE-T：UTP Cat. 5、5e UTP/STP
|
|
|
IEEE 802.3X (Full-Duplex mode)、 Back Pressure(Half-Duplex mode)
|
Forwarding/Filtering Rate
|
14481 packets/second per port@10Mbps
144810 packets/second per port@100Mbps
1448095 packets/second per port@1000Mbps
|
|
|
Max 9216 byte
|
|
|
AC 100~240V
|
|
|
Metal
|
|
Operating Temperature
|
0～50℃
|
|
Operating Humidity
|
＜80%
|
|
Storage Temperature
|
-20～60℃
|
|
Storage Humidity
|
＜95%
|
|
Power Requirements
|
AC100-240V
|
|
rated frequency
|
50/60Hz
|
