GDCA-001-30 years focus on CATV, MATV & SAT TV. Network Communication OEM/ODM manufacturer

GDCA-001

(RG179 CABLE )

咨询热线：0755-27091915

Place of Origin:Guangdong,China
Model Number:GDCA-001 (RG179 CABLE )
ITEM	Description
1.Cable	RG179
2.Length	600±10mm
3.Connector	F Type Male/Female
4.Impedance	75 ohm
5.Cable Outside Diameter	2.5mm
6.Operating Temperature	-30℃ to +70 ℃
7.Electrical Performance
Insertion Loss
-0.5dB Typical	5-1000MHz
-1.0dB Typical	1001-2150MHz
-1.2dB Typical	2151-2400MHz
-1.5dB Typical	2401-3000MHz
Return Loss
-25dB Typical	5-1000MHz
-20dB Typical	1001-2150MHz
-18dB Typical	2150-3000MHz
