Gdm-013 agile modulator
6213A
The 6213A Modulator is used for creating an in-home television channel tor viewing trom any Tin the home.A single signal from audio/video sources such as TV.VCR.DVD.DBS.or satellite TV.may be identified and displayed on any television.
Consultation hotline：0755-27091915
Online ServiceParameter
| Place of Origin: Guangdong,China | |
| Model Number：GDM-013 (6213A) | |
| Output CH.No.Of Modulator | 3 CH.Programmable |
| Output Channel | CH.14-CH.83 |
| TV Mode: | CH.65-CH.139 |
| CATV Mode: | Standard/HRC/IRC Selectable |
| Output Level | 73dBuV Double Side Band! |
| Audio Frequency Stability | ±10 KHz. |
| Video Frequency Stability | ±10 KHz. |
| Video Input Impedance | 75 ohm |
| Audio Input Impedance | 10K ohm |
| RF Output Impedance | 75 ohm |
| Ant. In | |
| Freq.Range | |
| Tnsertion Loss (Ant.In To RF Out) | |
| Impedance | |
| Level Control Range(Ant In To RF Qutl) | |
| Power Requirement | UL Power Adapter |
